1、  Chipset Feature

• Integrated      10/100/1000M transceiver

• Auto-Negotiation      with Next Page capability

• Supports USB      3.0, 2.0, and 1.1

• Supports      CDC-ECM

• Supports      LPM (Link Power Management)

• Supports      pair swap/polarity/skew correction

• Crossover      Detection & Auto-Correction

• Supports Wake-On-LAN      and ‘RealWoW!’

• Supports ECMA-393 ECMA ProxZzzy      Standard for sleeping hosts

• Supports      power down/link down power saving

• Transmit/Receive      on-chip buffer support

• EEPROM      Interface

• Embedded      OTP memory can replace external EEPROM

• Built-in      switching regulator and LDO regulator

• Supports      Customizable LEDs

• Supports      hardware CRC (Cyclic Redundancy Check) function

• LAN      disable with GPIO pin

• Supports      25MHz or 48MHz external clock (from oscillator or system clock source)

• SPI Flash      Interface

• 40-pin QFN      ‘Green’ package

•

• Note 1.      Select between RealWoW! or ECMA, only one feature can be active at a time.

Software Offload

• Microsoft      NDIS5, NDIS6 Checksum Offload (IPv4, IPv6, TCP, UDP) and Segmentation      Task-offload (Large send v1 and Large send v2) support

• Supports      jumbo frame to 9K bytes

IEEE

• Supports Full Duplex flow control (IEEE 802.3X)

• Fully compliant with IEEE 802.3,IEEE 802.u,and      IEEE802.3ab

• Supports IEEE 802.1P Layer 2 Priority Encoding

• Supports IEEE 802.1Q VLAN tagging

• Supports IEEE 802.az-2010(EEE)

Microsoft AOAC (Always On Always Connected)

• Supports 32-set      128-byte Wake-Up Frame pattern exact matching

• Supports      link change wake up

• Supports      Microsoft WPD (Wake Packet Detection)

• Supports      Protocol Offload (ARP & NS)

Intel CPPM (Converged Platform Power Management)

• Supports      L1 with 3ms BESL (USB 2.0)

• Dynamic      LTM messaging (USB 3.0)

• Supports      U1/U2 (USB 3.0)

• Supports selective suspend

2、Product specification
